Suzuki Samurai 1986 - 4-Wheel Drive LOW (All-Wheel Drive on LOW); Gear Ratio Data

4-Wheel Drive LOW (All-Wheel Drive on LOW)
Gear shift control lever position
4-wheel
drive LOW
2H
5l
Front shifterforkactuates front clutch to couple
rear shaft to front shaft; and rear shifter fork
actuates rear clutch to couple “low” gear to rear
shaft. Front shaft and rear shaft run together on From
LOW.
To front whe
Fig. 14-4
14-3. GEAR RATIO DATA
Gear
Reduction
Rear-wheel drive
41/44 - 62/41
1.409
All-wheel drive high
41/44 62/41
-
1.409
All-wheel drive low
41/44 - 56/23
2.268
14-4
