19-2. FRONT DISC BRAKE 4) Remove caliper (cylinder).
REMOVAL
1) Loosen, but do not remove, front wheel nuts.
2) Hoist car.
3) Remove wheel nuts and take off front wheels.
Brake Pad
After taking down the wheel, remove brake
pads according to the following procedure.
1) Remove caliper antirattle clip.
Fig. 19-17
2) Remove caliper guide pin caps (2 pcs).
3) Remove caliper guide pins (2 pcs) by using 6
mm hexagon wrench.
NOTE:
During removal, be careful not to damage brake
flexible hose.
Also, don’t depress brake pedal.
5) Remove pads.
Fig. 19-20
Fig. 19-18
19-14
