16-7. MAINTENANCE SERVICES
Inspection
Inspect differential and differential housing for
evidence of oil leakage.
Oil level ‘is checked by means of its oil level
plug. Refer to p 1-20 for level inspection,
Fig. 16-33 @ Drain plug
CD Oil level & filler plug
Oil Change
1 ) Remove oil drain plug and drain oil.
2) Reinstall drain plug and tighten it to specified
tightening torque.
3) Remove oil level & filler plug and fill diffe-
rential housing with new specified oil.
Differential oil
Hypoid gear oil
specification
SAE 8OW-90,75W-80 or 75W-90
Oil
Front
2.0 litres (4.2/3.5 US/Imp pt.)
capacity
Rear
1.5 litres (3.2/2.6 US/Imp pt.)
It is highly recommended to use SAE 75W-90
gear oil.
For viscosity chart, refer to P. 1-20.
16-8. RECOMMENDED TORQUE
SPECIFICATIONS
I
Tightening torque
I
I
Fastening parts
N.m
1 kg-m 11
Side bearing cap
bolt 70
- 100 7.0 - 10.0
51 .O - 72.0
Drive bevel gear
bolt 80
- 90 8.0 - 9.0
58.0 - 66.0
Differential case
bolt
37-45
3.7 - 4.5
27.0 - 32.5
I
4) Reinstall oil level & filler plug and tighten it
to specified tightening torque.
16-16
Side bearing adjuster
lock bolt
Differential carrier
bolt
Oil level & filler plug
Oil drain plug
