© 2003 - 2008 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO350/352/353/450/452/453
PREVENTIVE MAINTENANCE (PM)
4 - 29
4
4.6 PM KIT
KIT name Component Part name Qty.
DEV-KIT-3520 Drum cleaning blade BL-3520D 1
Separation finger for drum SCRAPER-DRUM 3
Main charger grid GRID-220 1
Main charger wire WIRE-CH-363 1
Transfer charger wire WEX-CH-060*353 1
Separation charger wire WEX-CH-060*353 1
Ozone filter FILTER-OZ-SPB-700B 1
Developer material D-3500 1
FU-KIT-3520 Fuser roller HR-3520-U 1
Pressure roller HR-3520-L 1
Separation finger for fuser roller SCRAPER-H/R 6
Cleaning roller SHAFT-CLAN-P/R 1
FU-KIT-3520T Fuser roller HR-3520-U-TWD 1
Pressure roller HR-3520-L 1
Separation finger for fuser roller SCRAPER-H/R 6
Cleaning roller SHAFT-CLAN-P/R 1
Leaf spring SPG-L-GND-TWD 1
ROL-KIT-16CST Pickup roller ROLLER-PICK-AT 1
Feed roller K-ROLL-FEED 1
Separation roller K-ROLL-PST 1
ROL-KIT-1010 Pickup roller ROLL-PICK-UP 1
Feed roller ROLL-PAPER-FED-F 1
Separation roller ROLL-PAPER-FED-S 1
DF-KIT-3015 Pickup roller ROLL-PICK-UP 1
Feed roller ROLL-FEED 1
Separation roller ROL-SPT-513 1
05/05
