POWER SUPPLY UNIT
7 - 1
7
7. POWER SUPPLY UNIT
7.1 Output Channel
The followings are five output channels which are not linked with the door switch.
1) +3.3V
+3.3VA: CN412 Pins 13, 14, 15 and 16
Output to the SYS board
+3.3VB: CN412 Pins 19 and 20
Output to the SYS board
+3.3VB: CN413 Pin 1
Output to the LGC board
+3.3VB: CN415 Pins 17 and 18
Output to the SLG board
2) +5.1V
+5.1VA: CN412 Pins 24 and 26
Output to the SYS board
+5.1VB: CN412 Pin 25
Output to the SYS board
+5.1VB: CN413 Pins 3 and 4
Output to the LGC board, PFP/LCF (via LGC board),
Bridge unit / Job separator / Offset tray (via LGC board)
+5.1VB: CN413 Pin 11
Output to the FIL board or FUS board
+5.1VB: CN415 Pins 5 and 6
Output to the RADF
+5.1VB: CN415 Pins 21 and 22
Output to the SLG board
+5.1VB: CN416 Pin 1
Output to the finisher
3) +12V
+12VA: CN412 Pin 7
Output to the SYS board
+12VB: CN412 Pin 5
Output to the SYS board
+12VB: CN413 Pin 7
Output to the LGC board
+12VB: CN415 Pin 15
Output to the SLG board
4) -12V (e-STUDIO350/450 only)
-12VA: CN412 Pin 9
Output to the SYS board
-12VB: CN412 Pin 3
Output to the SYS board
5) +24V (e-STUDIO350/450 only)
+24VB: CN413 Pin 13
Output to the FAX board
