e-STUDIO350/352/353/450/452/453 © 2003 - 2008 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE AND SELF-DIAGNOSTIC MODE
2 - 68
410 Laser Adjustment of primary
scanning laser writing start
position.
PPC 128
<0-255>
M When the value
increases by “1”, the
writing start position
shifts to the front side
by approx. 0.0423mm.
1
411 PRT 128
<0-255>
M
421 Drive Adjustment of secondary
scanning direction repro-
duction ratio (fine adjust-
ment of main motor speed)
PPC/
PRT
138
<0-255>
M When the value
increases by “1”, the
reproduction ratio of
secondary scanning
direction increases by
approx. 0.04%.
1
422 FAX 139
<0-255>
M
424 Drive Fine adjustment of exit
motor speed
PPC/
PRT
107
<0-255>
M When the value
increases by “1”, the
rotation becomes faster
by approx. 0.05%.
1
425 FAX 121
<0-255>
M
430 Image Top margin adjustment
(blank area at the leading
edge of the paper)
PPC 0
<0-255>
M When the value
increases by “1”, the
blank area becomes
wider by approx.
0.0423mm.
1
431 Image Left margin adjustment
(blank area at the left of the
paper along the paper
feeding direction)
PPC 0
<0-255>
M1
432 Image Right margin adjustment
(blank area at the right of
the paper along the paper
feeding direction)
PPC 0
<0-255>
M When the value
increases by “1”, the
blank area becomes
wider by approx.
0.0423 mm.
1
433 Image Bottom margin adjustment
(blank area at the trailing
edge of the paper)
PPC 0
<0-255>
M1
434-0 Image Bottom margin adjustment
(blank area at the trailing
edge of the paper)/
Reverse side at duplexing
PPC/
PRT
EUR: 48
UC:24
JPN: 24
Others:
48
<0-255>
M4
434-1 Image Right margin adjustment
(blank area at the right of
the paper along the paper
feeding direction)/Reverse
side at duplexing
PPC/
PRT
12
<0-255>
M4
435 Image Top margin adjustment
(blank area at the leading
edge of the paper)
PRT 24
<0-255>
M1
436 Image Left margin adjustment
(blank area at the left of the
paper along the paper
feeding direction)
PRT 0
<0-255>
M1
437 Image Right margin adjustment
(blank area at the right of
the paper along the paper
feeding direction)
PRT 0
<0-255>
M1
438 Image Bottom margin adjustment
(blank area at the trailing
edge of the paper)
PRT 0
<0-255>
M1
Adjustment mode (05) <e-STUDIO352/353/452/453>
Code
Classifi-
cation
Items
Func-
tion
Default
<Accept-
able
value>
RAM Contents
Pro-
cedur
e
07/11
