© 2003 - 2008 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO350/352/353/450/452/453
FIRMWARE UPDATING
6 - 1
6
6. FIRMWARE UPDATING
In this equipment, following firmware is written on the ROM on each board.
When you want to update the firmware above or the equipment becomes inoperative status due to
some defectives of the firmware, updating the firmware is available by the following actions.
<e-STUDIO350/450>
• Updating with the download jig
P. 6-3 "6.1 Firmware Updating with Download Jig (e-STUDIO350/450)"
• Updating with PC connected
P. 6-66 "6.3 Firmware Updating with FSMS (Field Service Manager) (e-STUDIO350/450)"
• Updating with the USB Storage Device
P. 6-79 "6.4 Firmware Updating with USB Storage Device (e-STUDIO350/450)"
<e-STUDIO352/353/452/453>
• Updating with the download jig
P. 6-34 "6.2 Firmware Updating with Download Jig (e-STUDIO352/353/452/453)"
• Updating with the USB Storage Device
P. 6-91 "6.5 Firmware Updating with USB Storage Device (e-STUDIO352/353/452/453)"
Firmware Stored Update method
Master data (HDD program data, UI data) Hard disk USB Storage Device
System ROM (System firmware, OS data,
UI data)
System control PC board (SYS board)
<e-STUDIO352/353/452/453>
The system firmware is stored into the
hard disk from the FROM basic section
software version “V1.00/4.22”.
USB Storage Device
* When replacing
the system control
PC board (SYS
board), update
with the Download
jig.
Engine ROM (Machine firmware) Logic PC board (LGC board) USB Storage Device
* Updating with the
Download jig is
also possible.
Scanner ROM (Scanner firmware) Scanning section control PC board (SLG
board)
USB Storage Device
* Updating with the
Download jig is
also possible.
NIC ROM (NIC firmware)
(e-STUDIO350/ 450 only)
NIC board Download jig
RADF ROM (RADF firmware) RADF control PC board (MR-3015/ MR-
3018)
Download jig
Finisher ROM (Finisher firmware) Finisher control PC board
(MJ-1023/ MJ-1024/ MJ-1101)
Download jig
Finisher ROM (Saddle stitcher firmware) Finisher control PC board (MJ-1024) Download jig
FAX ROM (FAX firmware) FAX board (GD-1150/ GD-1200) Download jig
07/11
