ERROR CODE AND SELF-DIAGNOSTIC MODE
2 - 39
2
[5]
A- --
B- --
C- --
D- --
E- --
F RADF connection RADF con-
nected
Not connected
G Platen sensor Platen cove
opened
Platen cove
closed
H Carriage home position sensor Carriage at
home position
Other than
home position
[6]
A- --
B- --
C- --
D APS sensor (APS-R) No original Original
present
E APS sensor (APS-C) No original Original
present
F APS sensor (APS-3) No original Original
present
G APS sensor (APS-2) No original Original
present
H APS sensor (APS-1) No original Original
present
[7]
A [RADF] Original tray sensor Original
present
No original
B [RADF] Original empty sensor Original
present
No original
C [RADF] Jam access cover sensor Cover opened Cover closed
D [RADF] RADF opening/closing sensor RADF opened RADF closed
E [RADF] Original exit/reverse sensor Original
present
No original
F [RADF] Original intermediate transport sensor Original
present
No original
G [RADF] Read sensor Original
present
No original
H
[RADF] Original registration sensor
Original
present
No original
[8]
A [RADF] Original tray width sensor (TWID0S)
(Refer to table3)
OFF (H) ON (L)
B [RADF] Original tray width sensor (TWID1S)
(Refer to table3)
OFF (H) ON (L)
C [RADF] Original tray width sensor (TWID2S)
(Refer to table3)
OFF (H) ON (L)
D
-
--
E [RADF] Original length detection sensor Original
present
No original
F [RADF] Original width detection sensor-1 Original
present
No original
G [RADF] Original width detection sensor-2 Original
present
No original
H- --
Digital
key
Button Items to check
Contents
Highlighted
display
e.g.
Normal dis-
play
e.g.
08/04
