14 Maintenance
414
Maintenance
14
Replacing the Staple Cartridge (For C-Finisher or C-Finisher with Booklet
Maker)
When the C-Finisher (optional) is installed and it is time to replace the staple cartridge,
a message appears on the touch screen. When the message appears, load a new
staple case into the staple cartridge.
This section explains how to replace the staple cartridge attached with the C-Finisher
with Booklet Maker. Use the same procedure for the C-Finisher.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and
performance. Use only staple cartridges recommended by Fuji Xerox.
Note • To order a new staple cartridge, contact our Customer Support Center.
1
Make sure that the machine has
stopped, and open the front cover
of the finisher.
2
Grip the lever R1 of the staple
cartridge holder, and pull out the
holder to the right, towards you.
3
Take out the staple cartridge holder
by gripping the orange lever.
Note • The staple cartridge is firmly
inserted. When taking the
staple cartridge out of the
machine, strongly pull it out.
4
Pick the empty staple case with
your fingers (1), and then remove
the case from the cartridge (2) as
shown in the figure.
Lever (R1)Lever (R1)
Orange lever
1
1
2
To Next Page
