Stapler Faults
533
Problem Solving
15
Staple Jams in the Staple Cartridge (For C-Finisher or C-Finisher with
Booklet Maker)
This section explains how to remove jammed staples from C-Finisher with Booklet
Maker (optional). Use the same procedure for C-Finisher (optional).
1
Make sure that the machine has
stopped, and open the front cover
of the finisher.
2
Grip Lever R1 of the staple
cartridge holder, and pull out the
holder to the right, towards you.
3
Take out the staple cartridge holder
by gripping the orange lever.
Note • The staple cartridge is firmly
inserted. When taking the
staple cartridge out of the
machine, strongly pull it out.
4
After removing the staple cartridge,
check the inside of the finisher for
any remaining staples.
5
Pull up the metal part of the staple
cartridge as shown in the figure.
Lever (R1)
Orange lever
To Next Page
