Accessories
26
Figure 10 Insert Battery into Cradle
Figure 11 Insert Extended Battery into Cradle
3. Ensure the battery is seated properly. The Spare Battery Charging LED blinks indicating charging.
Battery Charging
The WT6000 Charging LED indicates the status of the battery charging in the device. The Spare Battery Charging
LED indicates the status of the spare battery charging. See Table 5 on page 26. The standard 3,350 mAh battery
fully charges in less than four hours at room temperature. The extended 5,000 mAh battery fully charges in
approximately five hours and 30 minutes at room temperature.
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). The device or cradle always performs battery
charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37°C (+98°F)) the device or
cradle may for small periods of time alternately enable and disable battery charging to keep the battery at
acceptable temperatures. The device and cradle indicates when charging is disabled due to abnormal
temperatures via its LED.
Table 5 Spare Battery Charging LED Indicators
State Indication
Off The WT6000, RS6000 or battery is not charging. The WT6000, RS6000 or battery
is not inserted correctly in the cradle. Cradle is not powered.
Solid Amber Battery is charging.
Solid Green Battery charging is complete.
Fast Blinking Red
(2 blinks/second)
Charging error, e.g.:
- Temperature is too low or too high.
- Charging has gone on too long without completion (typically eight hours).
Solid Red Unhealthy battery is charging or fully charged.
