Corrective Maintenance
214
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Sensor Assemblies
S
Tools Required
Remove the Electronics Cover
1.
2.
Caution • A qualified service technician must perform this installation.
Tools • You need these tools to complete this procedure:
 Phillips Screwdriver Set
 Flat-blade Screwdriver Set
 Safety Glasses
 Metric Hex Key (Allen Wrench) Set
 Antistatic Wriststrap and Pad
 Metric Nutdriver Set
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media door and remove the media and ribbon.
