General| Max Print Width | 4.09 inches (104 mm) |
|---|---|
| Max Print Speed | 10 inches per second (254 mm per second) |
| Print Method | Thermal Transfer/Direct Thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Connectivity | USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless |
| Media Width | 1"/25.4 mm to 4.5"/114 mm |
| Media Length | 0.25 to 39 inches (6 to 991 mm) |
| Media Thickness | 0.0023"/0.058 mm to 0.010"/0.25 mm |
| Ribbon Width | 1"/25.4 mm to 4.33"/110 mm |
| Ribbon Length | 1476 feet (450 m) |
| Supported Media Types | Continuous, die-cut, notch, black-mark |
| Operating Temperature | 40°F to 105°F (5°C to 40°C) |
| Storage Temperature | -40°F to 140°F (-40°C to 60°C) |
Identifies the intended audience for this maintenance manual and the printer.
Explains the structure and organization of the maintenance manual's sections.
Provides contact information for Zebra Technologies by region: Americas, Europe, and Asia Pacific.
Lists the official Zebra website and the technical support portal for assistance.
Details text formatting, display examples, command line, and file/directory conventions.
Explains the meaning of various icons used in the manual for caution, importance, notes, and examples.
Provides visual identification of external printer components and connections.
Details the printer's media compartment, control panel, buttons, and lights.
Covers printer language modes, firmware, general, printing, media, and ribbon specifications.
A checklist of essential steps and considerations before setting up or operating the printer.
Guides on selecting a site, operating conditions, data sources, power, and communication interfaces.
Instructions for loading media and ribbon correctly, including ribbon overview.
Procedures for printer calibration, entering setup mode, and adjusting parameters.
Provides systematic checks for common printer errors and operational problems.
Lists LCD error messages, their possible causes, and recommended solutions.
Identifies common print quality issues, their causes, and recommended solutions.
Explains how to use printer diagnostics and self-tests for troubleshooting.
Details cleaning schedules and procedures for printer exterior, printhead, sensors, and cutter.
Provides replacement and installation procedures for major printer components like print system and sensors.
Step-by-step instructions for removing and installing the printhead assembly.
Procedures for removing and installing the print mechanism and associated parts.
Instructions for replacing printhead cables, ribbon strip plate, and printhead latches.
Guide to adjusting printhead pressure dials for optimal print quality.
Detailed steps for removing and installing sensor assemblies and their connections.
Instructions for replacing the drive belt and associated pulleys and gears.
Procedures for removing and installing the stepper motor and its related components.
Steps for replacing the ribbon take-up spindle clutch and spindle assembly.
Covers maintenance for ribbon supply spindle, media hanger, tear-off bar, static brush, cutter, and peel options.
Detailed instructions for removing and installing the platen roller assembly.
Procedures for maintaining the platen coupling and replacing the pinch roller.
Steps for removing and installing the printer's control panel.
Procedures for replacing the main logic board, wireless, and wired ethernet boards.
Instructions for removing and installing the electronic cover and media door.
Procedures for replacing the media window, lower front panel, and rear end cap.
Illustrations and part lists for outer casings, media door, rear end cap, and media/ribbon path.
Diagrams and part numbers for media hanger, sensors, spindles, print mechanism, and housing.
Drawings of drive system components, logic board, wireless, and wired ethernet boards.
Illustrations and part lists for media handling options like cutter, peel, liner take-up, and inside coated spindle.
