Ribbon Take-Up Spindle Clutch
Ribbon Take-up Spindle Clutch
266
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Ribbon Take-up Spindle Clutch
Tools Required
Remove the Electronics Cover
1.
2.
Tools • You need these tools to complete this procedure:
 Phillips Screwdriver Set
 Metric Hex Key (Allen Wrench) Set
 Metric Nutdriver Set
 Antistatic Wriststrap and Mat
 Metric Feeler Gauges; must include:
0.50 mm
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media door and remove the media and ribbon.
