335
Corrective Maintenance
Peel Maintenance Assembly
8/9/07
ZM400/ZM600 Maintenance Manual
14207L-001 A
Inst
all the New Peel Assembly
1.
See
Figure
197
. Install the two mounting
screws from the kit, using the hex key (Allen
wrench) supplie
d, into the tea
r bar mounting
screw holes.
T
ighten them to within 1/
4 in. of
the platen housing.
Figure 197 • Install Peel Assembly
1
Peel assembly
2
Mounting slots
(2)
3
Mounting screws (2)
4
Platen housing
5
Rest pems on housin
g here.
6
Peel lever
1
2
3
334
336
