Zebra ZM400 Series User Manual

301
Corrective Maintenance
Ribbon Supply Spindle
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Ribbon Supply Spindle
Tools Required
Remove the Electronics Cover
1.
2.
Tools • You need these tools to complete this procedure:
 Phillips Screwdriver Set
 Antistatic Wrist Strap and Pad
 Metric Hex Key (Allen Wrench) Set
Caution • A qualified service technician must perform this installation.
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media cover and remove the media and ribbon.
