261
Corrective Maintenance
S
tepper Motor
Assembly
8/9/07
ZM400/ZM600 Maintenance Manual
14207L-001 A
Gain Access to the Power Supply
1.
See
Figure
127
. Remove the standoff from the upper left of the power supply
shield.
2.
Remove the mounting screw from t
he upper ri
ght of the pow
er supply shield.
Figure 127 • Remove the St
andof
f and Screw
1
Mounting scre
w
2
Sta
n
do
ff
3
Power supply shield
2
1
3
260
262
