Corrective Maintenance
Platen Roller
8/9/07
ZM400/ZM600 Maintenance Manual
14207L-001 A
Inst
all the New Platen Roller Assembly
1.
See
Figure
224
. V
erify that t
he bearings are oriented pro
perly
.
Figure 224 • Bearing Keys
Import
ant •
The grooves in the inner and ou
ter bearings must be facing up
.
1
Inner bearing
2
Inner bearing g
rooves
3
Outer bearing grooves
4
Outer bearing
1
3
2
4
