Corrective Maintenance
Media Hanger
316
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Media Hanger
Tools Required
Replace the Old Hanger Assembly
1.
2.
Tools • You need these tools to complete this procedure:
 Metric Nutdriver Set
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media cover and remove the media and ribbon.
To Next Page
