Corrective Maintenance
Platen Coupling
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Reinstall the Platen Roller
1. See Figure 239. Verify that the bearings are oriented properly.
Figure 239 • Bearing Keys
Important • The grooves in the inner and outer bearings must be facing up.
1
Inner bearing
2
Inner bearing grooves
3
Outer bearing grooves
4
Outer bearing
1
3
2
4
