ABB | SACE Emax 2
Ekip Touch protection trip unit | 22 - Default parameters129 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
22 - Default parameters
Ekip Touch default parameters
The Ekip Touch trip units are supplied with the following default parameters:
Protection/Parameter
Value
(1)
L 1 In; 144 s; pre-alarm: 90 %
S
(2)
Off; 2 In; 50 ms; Curve: t = k
I 4 In
G
(2)
Off; 0.2 In; 400 ms; Curve: t = k
2I Off; 1.5 In
MCR Off; 6 In; 40 ms
IU Off; 50%; 5 s
OT Off
I1 current thresholds Off; 1: 50 %; 2: 75 %
Current thresholds Off; Iw1: 3 In; Iw2: 3 In
Harmonic Distortion On
Gext
(2) (3)
Off; 0.2 In; 400 ms; Curve: t = k
Rc
(3)
Off; 3 A; 60 ms
Frequency 50 Hz (IEC) / 60 Hz (UL)
Neutral
Off (for circuit breakers three-pole)
50 % (for four-pole circuit-breaker)
Datalogger Off
Power Controller See note
(4)
Hardware Trip Disabled
Monitor time 5 minutes
Local Bus Disabled
Alive LED Disabled
Language English
Password 00001
Mode Local
Modbus RTU par Address: 247; baudrate: 19.2 Kbit/s
Profibus Address: 125
DeviceNet™ MAC ID: 63; baudrate: 125 Kbit/s
Modbus TCP/IP Static IP: 0.0.0.0
Maintenance Off
(1)
Thermal memory, startup, Zone Selectivity set to Off.
(2)
S Protection available with LSI and LSIG versions of the trip unit. G Protection available with LSIG version.
(3)
Protections available if the respective toroids (S.G.R. or Rc) are present.
(4)
Protection activated on request when purchasing the trip unit.
The protections activated by the presence of the Ekip Measuring Pro module, have the following default
parameters:
Protection/Parameter Value
VU Off; 50%; 5 s
UV Off; 0.9 Un; 5 s
OV Off; 1.05 Un; 5 s
UF Off; 0.9 fn; 3 s
OF Off; 1.1 fn; 3 s
RP Off; 0.1 Sn; 10 s
Phase Sequence 1-2-3
Cos φ Off; 0.95
Continued on the next page
