ABB | SACE Emax 2
Ekip Touch protection trip unit | 6 - Menu49 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
Settings Menu
This menu allows you to configure more settings in addition to those of the protections and of the advanced
protections and functions.
The following table shows the submenus and the parameters associated to the menu Settings, up to Level
3 (if present). The options corresponding to parameters and commands are underlined, to distinguish from
those corresponding to submenus.
Settings
Options
Circuit Breaker
• Configuration: available with a three-pole circuit-breaker, it opens a list of the
possible configurations of the circuit-breaker neutral.
• Hardware Trip: it opens the Modify Parameters page, to enable/disable tripping in
the case of hardware problem of the trip unit.
• T Protection: it opens a list of the parameters that can be set for the
overtemperature protection.
• Neutral Protection: available with a configuration with neutral, it opens a list of the
parameters that can be set.
• Ground protection: it opens a list of the parameters that can be set.
• Installation: displayed if a Rating Plug or Ekip Measuring or Ekip Measuring Pro
module is not installed. It opens a list of the modules to be installed.
Main frequency It opens the Modify Parameters page, to set the Line frequency.
Phase Sequence It opens the Modify Parameters page, to set the phase sequence.
Modules
(1)
• Local/Remote: it opens the Modify Parameters page, to set the local or remote
connection.
• Local Bus: it opens the Modify Parameters page, to enable/disable the Local Bus
• Ekip Measuring, Ekip Synchrocheck, etc: these open a list of the parameters that
can be the set for the electronic accessories.
• Functions: it allows the access to the menus in order to program Switch On
LOCAL, Signalling RESET, YO Command, and YC Command actions (see the
chapter "20 - Operating features", and the paragraph "Functional characteristics", on
page 124).
Monitor time
It opens the Modify Parameters page, to set the waiting time between the acquisition
of one measurement and the next.
Power
Controller
• Enable: it opens the Modify Parameters page, to enable/disable the function.
• Load Operating Mode: available with Power Controller enabled, it opens a list of the
loads, to be enabled/disabled.
• Power Limits: available with Power Controller enabled, it opens a list of the power
thresholds to be set.
Network
Analyzer
• Enable: it opens the Modify Parameters page, to enable/disable the function.
• I Harm Analysis: available with Network Analyzer enabled, it opens the Modify
Parameters page to enable/disable the calculation of the harmonics for currents.
• V Harm Analysis: available with Network Analyzer enabled, it opens the Modify
Parameters page to enable/disable the calculation of the harmonics for voltages.
• V Threshold Low, V Threshold High, Umbalance Th, V microinterr. Th, V Spike Threshold:
available with Network Analyzer enabled, they open the Modify Parameters page,
to set the parameters (for details on the parameters, see the chapter "17 - Hi-Touch
measurements", and the paragraph "Network Analyzer", on page 114).
• Sags: available with Network Analyzer enabled, it opens a list of the parameters that
can be set for monitoring voltage drops.
• Swells: available with Network Analyzer enabled, it opens a list of the parameters
that can be set for monitoring voltage swells.
Datalogger
(2)
• Enable: available if the function is not running, it opens the Modify Parameters page
to enable/disable the function.
• Num. of Datalogger: available with Datalogger enabled, it opens the Modify
Parameters page, in order to set the number of records.
• Sampling frequency: available with Datalogger enabled, it opens the Modify
Parameters page, to set the frequency of data logging.
• Datalogger 1: available with Datalogger enabled, opens a list of the parameters that
can be set and the commands of the function.
• Datalogger 2: available with the second Datalogger enabled, it opens a list of the
parameters that can be set and the commands of the function.
• Restart all: available with the second Datalogger enabled, it starts both recordings.
• Stop all: available with the second Datalogger enabled, it stops both recordings.
Continued on the next page
