Ekip Dip protection trip unit | 5 - List of alarms and signals29 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
5 - List of alarms and signals
LED view
The Ekip Dip trip unit continuously monitors its own operating condition and that of all the devices to which
it is connected. All the signals are available with the front LEDs.
The protection LEDs provide information with various combinations of lighting and flashing, while the power-
on LED, as described on page 19, indicates the power-on conditions of the trip unit.
Figure 3
NOTE: the number of LEDs depends on the version of the trip unit (LI, LSI, LSIG).
