ABB | SACE Emax 2
240 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A Electronic accessories | 14 - Ekip Link module
Access from the display
With the module energized, and the Local Bus enabled, the presence of the module itself on the terminal box
activates additional menus on the display:
• To set the addressing of the module.
• To display information on the module.
To enable the Local Bus, you need to select "On" in the menu Settings - Modules - Local Bus.
The following table shows the path from the display to set the addressing of the module:
Settings
…
Main frequency
Modules
Local/Remote
Local Bus
…
Ekip Link
Force Static IP address
Static IP Address
Static Network Mask
Static Gateway addr
…
Functions
Power Controller
…
The following table shows the configuration parameters for the addressing of the module: For further
information, see the table on page 241.
Parameter Selectable values Default Description
Force Static IP
address
Off, On Off
• Off = Dynamic IP address.
• On = Static IP address.
Static IP Address
Displayed with static IP Address enabled, it must be selected in order to insert the
IP Address of the module.
Static Network Mask
Displayed with static IP Address enabled, it must be selected in order to insert the
subnet mask of the module.
Static Gateway addr
Displayed with static IP Address enabled, it must be selected in the presence
of multiple subnets, in order to insert the IP Address of the node to which the
module is connected.
The following table shows the path from the display for accessing information on the module:
About
Protection Unit
Circuit-breaker
Modules
…
Ekip Link
…
Power Controller
Continued on the next page
