ABB | SACE Emax 2
System Interface | 8 - External toroid protections155 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
System Interface
Documents
For correct use of Ekip Com communication modules, two documents are available in the ABB library:
Document Description
1SDH001140R0001
Guidelines with details for putting communication modules into
service.
1SDH001140R0001_CSI_Emax2
Table with the references of all the registers for the parameters,
commands, measurements, etc.
The documents are available in a single .zip file (1SDH001140r0001).
The .zip file contains the files for integrating Emax 2 in the available communication networks. The specific
Ekip Com module contains an IMPORTANT file with notes on how to use the files.
File Protocol / Ekip Com module
ABBS0E7F.gsd .gsd file for the configuration of the Ekip Com Profibus DP module
Ekip COM EtherNetIPTM_v02.eds .eds file for the configuration of the Ekip Com EtherNet/IP™ module
Ekip_COM_DeviceNetTM_v02.eds .eds file for the configuration of the Ekip Com DeviceNet™ module
emax2_v02_00_2003.icd .icd file for the configuration of the Ekip Com IEC 61850 module
emax2_v02_00_2003_Citect.icd .icd file for the configuration of the Ekip Com IEC 61850 module
GSDML-V2.3-ABB S.p.A.-SACE
Emax 2-20130924.xml
.xml for the configuration of the Ekip Com Profinet module
NOTE: consult the ABB library for the most recent version of the .zip file.
