ABB | SACE Emax 2
Ekip Touch protection trip unit | 3 - Histograms Page43 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
Continued from the previous page
Pos. Description
D
Signalling and functions in progress:
•
Remote connection, visible with auxiliary voltage and Ekip Com accessory
modules.
•
o Auxiliary voltage or Test connection.
•
or If the Dual Set function is enabled (see Settings menu), the letter
identifies the activated configuration.
E Current time.
F
• Measurement of the maximum phase current, as an absolute value (Ampere).
• Phase to which the measurement refers.
G
Displayed with the Ekip Measuring module:
• Measurement of the maximum phase-to-phase voltage, as an absolute value (Volt).
• Concatenated to which the measurement refers.
H
Viewed with the Ekip Measuring module, it indicates the presence of several pages,
that you can scroll through by touching the sides of the display, and in which of these
pages you are.
I Diagnosis bar.
Possible operations
If Ekip Measuring or Ekip Measuring Pro are installed, access the histogram page and press the sides of the
display to access a page containing a summary of the main measurements (maximum phase current, line-to-
line overvoltage, power factor, active, reactive and apparent power). If Ekip Synchrocheck is also available,
there is a further page with a summary of the main measurements associated with the module (Int and Ext
voltages and frequencies, phase difference, synchronism state).
Both pages can be set as main page by pressing and holding down the HOME key.
