ABB | SACE Emax 2
Introduction to Ekip trip units | 1 - Presentation17 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
Accessorizing modules
The Emax 2 circuit-breakers and Ekip trip units can be equipped as indicated in the combination tables on
page 165.
Various types of modules are available, differing in functionality and in their position on the circuit-breaker.
The modules that can be connected directly to the electronic trip unit are:
Name Description Page
Ekip Measuring
Ekip Measuring Pro
Power supply, protection and measurement modules. 179
Ekip Signalling 4K Signalling module 193
NOTE: the Ekip Signalling 4K module is not available for E1.2 circuit-breakers.
The modules available for the terminal box of the circuit-breaker are:
Name Description Page
Ekip Supply Power supply module 177
Ekip Signalling 2K Signalling module 200
Ekip Synchrocheck
Module for measuring voltage and synchronism between two
power sources
185
Ekip Com Modbus RTU
Ekip Com Profibus DP
Ekip Com DeviceNet™
Ekip Com Modbus TCP
Ekip Com Profinet
Ekip Com EtherNet/IP™
Ekip Com IEC 61850
Communication module 208
Link Communication module 237
The modules external to the circuit-breaker are:
Name Description Page
Ekip Multimeter Power supply and measurement module 246
Ekip Signalling 10K Signalling module 247
Ekip Signalling Modbus TCP Remote control and monitoring module 247
The supervision, configuration and reporting functions are, in addition, guaranteed by further modules for
temporary power supply and communication (test modules):
Name Description Page
Ekip TT Power supply and test module 246
Ekip T&P Power supply, communication and test module 246
Ekip Programming Power supply, communication and programming module 246
Ekip Bluetooth Power supply and communication module 245
Information about the LCD version of the trip units is available from page 244.
