ABB | SACE Emax 2

7 - Installation

Dimensions

Information on the overall dimensions is available on the website:

http://www.abb.com/abblibrary/DownloadCenter/.

The following drawings are also available in .dxf format:

• 1SDH000999r0101 - E1.2 III-IV Fixed F EF IEC-UL

• 1SDH000999r0102 - E1.2 III-IV Fixed FC IEC-UL

• 1SDH000999r0103 - E1.2 III-IV Withdrawable EF IEC-UL

• 1SDH000999r0104 - E1.2 III-IV Withdrawable ES IEC-UL

• 1SDH000999r0105 - E1.2 III-IV Withdrawable SHR IEC

• 1SDH000999r0106 - E1.2 III-IV Withdrawable FC IEC

• 1SDH000999r0107 - E1.2 III-IV Fixed HR-VR Positionable IEC

• 1SDH000999r0108 - E1.2 III-IV Fixed ES IEC-UL

• 1SDH000999r0109 - E1.2 III-IV Withdrawable HR-VR IEC

• 1SDH000999r0120 - E1.2 Flange Fixed Withdrawable IEC-UL

• 1SDH000999r0121 - E1.2 Floor mounting IEC-UL

• 1SDH000999r0303 - E1.2 III-IV Withdrawable Rear Terminals HR-VR UL

• 1SDH000999r0307 - E1.2 III-IV Fixed Rear Terminals HR-VR UL

• 1SDH001000r0100 - E2.2 III-IV Fixed HR VR IEC

• 1SDH001000r0101 - E2.2 III-IV Fixed F IEC-UL

• 1SDH001000r0102 - E2.2 III-IV Withdrawable HR-VR IEC

• 1SDH001000r0103 - E2.2 III-IV Withdrawable F IEC

• 1SDH001000r0104 - E2.2 III-IV Fixed SHR IEC

• 1SDH001000r0105 - E2.2 III-IV Withdrawable SHR IEC

• 1SDH001000r0106 - E2.2 III-IV Fixed SVR IEC

• 1SDH001000r0107 - E2.2 III-IV Withdrawable SVR IEC

• 1SDH001001r0100 - E4.2 III-IV Fixed HR VR IEC

• 1SDH001001r0101 - E4.2 III-IV Fixed F IEC

• 1SDH001001r0102 - E4.2 III-IV Withdrawable HR-VR IEC

• 1SDH001001r0103 - E4.2 III-IV Withdrawable F IEC

• 1SDH001060r0100 - E6.2 III-IV Fixed HR IEC

• 1SDH001060r0101 - E6.2 III-IV Fixed VR IEC

• 1SDH001060r0102 - E6.2 IV FS Fixed HR-VR IEC

• 1SDH001060r0104 - E6.2 III-IV Fixed F IEC

• 1SDH001060r0105 - E6.2 III-IV Withdrawable HR IEC

• 1SDH001060r0106 - E6.2 III-IV Withdrawable VR IEC

• 1SDH001060r0107 - E6.2 IV FS Withdrawable HR-VR IEC

• 1SDH001060r0108 - E6.2 III-IV Withdrawable F IEC

• 1SDH001000r0120 - E2.2-E4.2-E6.2 Fixed Withdrawable Flange IEC-UL

• 1SDH001000r0121 - E2.2-E4.2-E6.2 Fixed internal mounting IEC-UL

• 1SDH001000r0300 - E2.2 III-IV Fixed HR-VR UL

• 1SDH001000r0302 - E2.2 III-IV Withdrawable HR-VR UL

• 1SDH001000r0303 - E2.2 III-IV Withdrawable F UL

• 1SDH001001r0300 - E4.2 III-IV Fixed HR-VR UL

• 1SDH001001r0302 - E4.2 III-IV Withdrawable HR-VR UL

• 1SDH001001r0303 - E4.2 III-IV Withdrawable F UL

• 1SDH001001r0304 - E4.2 III-IV Fixed HR-VR UL

• 1SDH001001r0305 - E4.2 III-IV Withdrawable HR-VR UL

• 1SDH001060r0300 - E6.2 III-IV Fixed HR UL

• 1SDH001060r0301 - E6.2 III-IV Fixed VR UL

• 1SDH001060r0302 - E6.2 IV FS Fixed HR-VR UL

• 1SDH001060r0305 - E6.2 III-IV Withdrawable HR UL

• 1SDH001060r0306 - E6.2 III-IV Withdrawable VR UL

• 1SDH001060r0307 - E6.2 IV FS Withdrawable HR-VR UL

• 1SDH001060r0308 - E6.2 III-IV-IV FS Withdrawable F UL

• 1SDH001060r0309 - E6.2 III-IV Fixed V UL

• 1SDH001060r0310 - E6.2 IV FS Fixed V UL

• 1SDH001060r0311 - E6.2 III-IV Withdrawable V UL

• 1SDH001060r0312 - E6.2 IV FS Withdrawable V UL

• 1SDH001000r0110 - E2.2 2000 III-IV Withdrawable FL IEC

• 1SDH001000r0111 - E2.2 2500 III-IV Withdrawable FL IEC

• 1SDH001001r0110 - E4.2 3200 III-IV Withdrawable FL IEC

• 1SDH001001r0111 - E4.2 4000 III-IV Withdrawable FL IEC

• 1SDH001060r0110 - E6.2 6300 III-IV Withdrawable FL IEC
