Protection curves | 3 - Touch protections141 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
Tripping curves for protection L
according to IEC 60255
Version SI
1
10
100
10000
1000
0,1
1010,1
x In
t [s]
3 .. 144
0,4..1
Version VI
1
10
100
10000
1000
0,1
1010,1
x In
t [s]
3 .. 144
0,4..1
