ABB | SACE Emax 2
Mechanical accessories | 2 - Mechanical safety accessories263 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A
Anti-insertion lock
The anti-insertion lock allows the moving part of the circuit-breaker to be inserted only into the corresponding
fixed part.
It is intended for all withdrawable circuit breakers.
E1.2 B-C-N
06
08
10
12
16
06
08
E1.2 L
10
12
02
E1.2 B-C-N
06
08
10
12
16
06
08
E1.2 L
10
12
02
Lock for E1.2
E
2
.
2
N
-
B
-
S
E
2
.
2
H
0
2
0
8
1
0
1
2 16
2
0
2
5
0
8
1
0
1
2
1
6
2
0
2
5
LEFT
MA
T
C
H
A
L
S
O
TH
E
R
I
GH
T
S
I
DE
Lock for E2.2 - E4.2 - E6.2
Information on the assembly is available on the website http://www.abb.com/abblibrary/DownloadCenter/,
in particular for E1.2 in the kit sheet 1SDH000999r0701 and for E2.2-E4.2-E6.2 in the kit sheet
1SDH001000r0701.
MOC: Operation counter
The mechanical operation counter displays the number of mechanical operations performed by the circuit-
breaker.
00001
MOC for E1.2
00001
MOC for E2.2 - E4.2 - E6.2
Information on the assembly is available on the website http://www.abb.com/abblibrary/DownloadCenter/,
in particular for E1.2 in the kit sheet 1SDH000999r0710 and for E2.2-E4.2-E6.2 in the kit sheet
1SDH001000r0710.
PLP: padlock in connected/
test/disconnected positions
The PLP locks the moving part of a withdrawable circuit-breaker in the fixed part, in one of the following
positions:
• connected
• test
• disconnected
Only one type is available that allows you to mount up to three padlocks with a diameter of 8 mm.
NOTE: the PLP lock can also be supplied in the presence of a KLP lock
PLP for E1.2 PLP for E2.2 - E4.2 - E6.2
Information on the assembly is available on the website http://www.abb.com/abblibrary/DownloadCenter/,
in particular for E1.2 in the kit sheet 1SDH000999r0707 and for E2.2-E4.2-E6.2 in the kit sheet
1SDH001000r0707.
