Position the specific tool (6) on the sta-
tor to obtain the correct distance of the
pick-up.
•
Push the pick-up at the point indicated,
towards the specific tool and tighten
the screws (5) to the prescribed torque.
Flywheel cover installation
To proceed with the installation of the flywheel
cover, proceed as described:
•
If removed during the disassembly
phase, position the two centring pins
(1) on the crankcase.
•
Position the gasket (2) on the crank-
case.
•
Position the cover (3) on the crank-
case.
Engine RS 660 - Tuono 660
ENG - 166
