Use a support to prevent the fork from
falling as a result of unscrewing the fix-
ing screw (6) on the upper triple clamp.
•
Extract and remove the stanchion (7).
•
During reassembly, pay attention to the adjustment of the stanchion protrusion, referring to
the "Adjustment" paragraph in the "Suspensions" chapter.
Draining oil
NOTE
THE FOLLOWING OPERATIONS REFER TO A SINGLE STANCHION BUT APPLY TO BOTH.
•
Clamp the forks in a vice with protected
jaws, taking care not to damage them.
•
Fully tighten the adjustment screw (1)
of the rebound damping.
Specific tooling
AP8140149 Guard for assembly operations
RS 660 - Tuono 660 Suspensions
SUSP - 243
