Insert the six screws (3) and tighten
them to the specified torque in the in-
dicated order (A-B-C-D-E-F).
Front brake pads
Removal
THIS VEHICLE IS FITTED WITH A DOUBLE DISC FRONT BRAKING SYSTEM (RIGHT AND LEFT
SIDE).
ALWAYS REPLACE ALL THE PADS FROM BOTH FRONT BRAKE CALLIPERS.
REPLACING THE PADS OF ONLY ONE FRONT CALLIPER MAY JEOPARDISE THE VEHICLE
STABILITY AND SAFETY, POSING SERIOUS DANGER FOR PEOPLE, OBJECTS AND THE VE-
HICLE ITSELF.
CAUTION
THE FOLLOWING OPERATIONS REFER TO A SINGLE CALLIPER, BUT APPLY TO BOTH.
To remove the front brake pads proceed as de-
scribed:
•
Remove the cotter pin (1) from the pin.
•
Remove the pin (2).
RS 660 - Tuono 660 Braking system
BRAK SYS - 353
