Release the expansion tank (6) at the
point indicated from the internal fairing
and remove it.
NOTES FOR INSTALLATION
•
To refit the expansion tank, first insert
the tab (7) on the tank in the appropri-
ate slot on the internal fairing and then
hook the tank in the centre in the point
indicated.
•
After reconnecting all pipes and filling the system with the indicated quantity of coolant,
check that there are no leaks in the coupling points of the pipes.
See also
Capacities
Thermostatic valve
Removing
To remove the thermostatic valve, it is necessary
to previously drain the cooling system. Then pro-
ceed as described:
•
After disconnecting the pipe from the
cover, remove the two screws (1) fas-
tening the cover itself.
Cooling system RS 660 - Tuono 660
COOL SYS - 376
