Remove the cam tower complete with
plate.
•
After removing the chain tensioner,
proceed with the removal of the intake
camshaft, removing the timing chain
from the gear on the shaft itself.
•
After removing the chain tensioner,
proceed with the removal of the ex-
haust camshaft, removing the timing
chain from the gear on the shaft itself.
CAUTION
PROCEED WITH CAUTION DURING THE REASSEMBLY PHASE SINCE THE CAMSHAFTS ARE
DIFFERENT.
Removing the valves
To proceed with the removal of the valves, proceed as described:
•
Position the head in a vice using the special protective jaws.
INTAKE VALVES
CAUTION
THE FOLLOWING OPERATIONS REFER TO A SINGLE INTAKE VALVE BUT ARE VALID FOR
BOTH.
Engine RS 660 - Tuono 660
ENG - 196
