APRILIA RS 660 2021 User Manual

•
Position the spring (2) and insert the
locking pin (3).
•
Tighten the locking pin to the specified
torque.
•
Insert split pin (4) in the pin.
•
Check the correct operation of the
brake system.
Rear brake pads
Removal
To remove the rear brake pads, remove the rubber
grommet, freeing the ABS sensor wiring harness
from the brake hose and then proceed as descri-
bed:
•
Remove the two brake calliper fixing
screws (1).
RS 660 - Tuono 660 Braking system
BRAK SYS - 355
