Check the condition of the pipe that
goes from the reservoir to the brake
pump, for cracks or cuts, replace it if
damaged.
NOTE
IF THERE IS ANY DAMAGE TO THE MASTER CYLINDER
OR THE PISTON, REPLACE IT.
Rear brake pump
Rimozione
To remove the rear brake pump it is necessary to
previously empty the oil from the system. Then
proceed as described:
•
Remove the safety O-ring (1) from the
pin that blocks the brake pump control
rod.
•
Rotate the pin (2) to release the brake
pump control rod and slide it out in or-
der to remove it.
•
Undo the fastener screw (3) of the oil pipe.
•
Ensure that the screw (4) cannot rotate
and unscrew the nut (5) to release the
oil reservoir from the frame.
RS 660 - Tuono 660 Braking system
BRAK SYS - 363
