Insert the thrust plate (13) complete
with the three lock screws (14).
•
Carefully and progressively, screw
down the three screws securing the
thrust plate following the order A-B-C.
CAUTION
PAY CAREFUL ATTENTION TO TIGHTENING THE THREE
SCREWS. ALWAYS PROCEED GRADUALLY AND PRO-
GRESSIVELY ON EACH SCREW.
•
Tighten the three screws securing the
thrust plate to the specified torque fol-
lowing the order A-B-C.
Installing the clutch cover
Before installing the clutch cover, if removed dur-
ing the disassembly phase, restore the cover com-
ponents as follows:
•
Place the gasket (1) of the blow-by sys-
tem on the crankcase, as indicated.
RS 660 - Tuono 660 Engine
ENG - 181
