APRILIA RS 660 2021 User Manual

Instrument panel
To remove the instrument panel, first the fairing
complete with light assembly must be removed.
Then proceed as described:
•
After unscrewing the two screws (1)
fastening the cover (2), remove it
•
Disconnect the connector (3) from the
instrument cluster.
•
Lift the instrument cluster (4) sufficient-
ly to allow the rubber blocks to be re-
moved from the slotted holes.
•
Undo the four screws (5).
RS 660 - Tuono 660 Bodywork
BODYW - 387
