Rear braking system
In order to top up the rear braking system, the rear
side fairing panel must be removed.
•
Unscrew the fastener screw (5) of the
rear brake reservoir while restraining
the nut to prevent it from turning.
•
Free the rear brake fluid reservoir (6).
•
Unscrew the cap (7) and remove to-
gether with the gasket (8).
•
Top up the reservoir (6) with recom-
mended brake fluid to above the mini-
mum level marking "MIN".
CAUTION
ONLY FILL TO THE "MAX" LEVEL AFTER FITTING NEW
BRAKE PADS. DO NOT FILL TO THE "MAX" LEVEL WITH
WORN PADS, AS THIS WILL CAUSE FLUID TO ESCAPE
WHEN REPLACING BRAKE PADS.
CHECK BRAKING EFFICIENCY.
IF THE DEAD ZONE OF THE BRAKE PEDAL OR BRAKE
LEVER IS TOO LONG, OR IN CASE OF FLUID LOSS, IT
MAY BE NECESSARY TO BLEED THE AIR TRAPPED IN
THE SYSTEM.
Adjusting the levers
FRONT BRAKE LEVER
It is possible to adjust the distance between the
end of the lever (1) and the grip (2), turning the
adjuster (3).
•
Push the control lever (1) forwards and
turn the adjuster (3) until the lever (1)
is at the desired distance.
•
Turning the adjuster anticlockwise, the
lever (1) gets closer to the grip (2).
RS 660 - Tuono 660 Maintenance
MAIN - 83
