Remove the two fixing screws (4) and
extract the license plate light (5) by re-
moving the wiring harness from the li-
cense plate holder.
Side body panels
To disassemble the side panels it is necessary to
first remove the saddles. Then proceed as descri-
bed:
The operations described refer to a side panel
but are valid for both
•
Remove the upper fastener screw (1).
•
Remove the lower fastener screw (2).
•
Move the front part (A) to the outside,
then by moving the side panel back-
wards (B) it is possible to release it (C).
RS 660 - Tuono 660 Bodywork
BODYW - 395
