Bosch Climate 5000i User Manual

Table of contents
53
Climate 5000i – 6721824787 (2021/02)
Table of contents 1 Explanation of symbols and safety instructions
1.1 Explanation of symbols
Warnings
In warnings, signal words at the beginning of a warning are used to
indicate the type and seriousness of the ensuing risk if measures for
minimizing danger are not taken.
The following signal words are defined and can be used in this document:
DANGER
DANGER indicates that severe or life-threatening personal injury will
occur.
WARNING
WARNING indicates that severe to life-threatening personal injury may
occur.
CAUTION
CAUTION indicates that minor to medium personal injury may occur.
NOTICE
NOTICE indicates that material damage may occur.
Important information
The info symbol indicates important information where there is no risk to
people or property.
Table 1
1 Explanation of symbols and safety instructions . . . . . . . . . .53
1.1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . .53
1.2 General safety instructions . . . . . . . . . . . . . . . . . . . . . .54
1.3 Notices regarding these instructions. . . . . . . . . . . . . . .54
2 Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
2.1 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . .55
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
2.3 Product dimensions and minimum clearances. . . . . . .55
2.3.1 Indoor unit and outdoor unit . . . . . . . . . . . . . . . . . . . . .55
2.3.2 Refrigerant pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
3 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
3.1 Before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
3.2 Requirements for installation site . . . . . . . . . . . . . . . . .55
3.3 Unit installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
3.3.1 Installing the indoor unit . . . . . . . . . . . . . . . . . . . . . . . .56
3.3.2 Installing the outdoor unit . . . . . . . . . . . . . . . . . . . . . . .56
3.4 Pipework connection . . . . . . . . . . . . . . . . . . . . . . . . . . .56
3.4.1 Connecting refrigerant pipes to the indoor and
outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
3.4.2 Connecting condensate pipe to the indoor unit . . . . . .57
3.4.3 Checking tightness and filling the system. . . . . . . . . . .57
3.5 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . .57
3.5.1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
3.5.2 Connecting the indoor unit . . . . . . . . . . . . . . . . . . . . . .57
3.5.3 Connecting the outdoor unit . . . . . . . . . . . . . . . . . . . . .58
4 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
4.1 Commissioning checklist . . . . . . . . . . . . . . . . . . . . . . . .58
4.2 Functional test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
4.3 Handover to the user . . . . . . . . . . . . . . . . . . . . . . . . . . .58
5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
5.1 Faults with indication . . . . . . . . . . . . . . . . . . . . . . . . . . .59
5.2 Faults without indication . . . . . . . . . . . . . . . . . . . . . . . .60
6 Environmental protection and disposal . . . . . . . . . . . . . . . . .61
7 Data Protection Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
8 Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Symbol Meaning
Warning regarding flammable substances: the R32
refrigerant used in this product is a gas with mild
combustibility and low toxicity (A2L or A2).
Maintenance by a qualified person should be done
while following the instructions of the service manual.
For operation follow the operating instructions for
users.

Bosch Climate 5000i Specifications

General

Type	Split system
Ionizer	Yes
Multi-split	No
Display type	LED
Product color	White
Gas hose diameter	9.52 mm
Hose length (max)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R32
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity (nominal)	12000 BTU/h
Refrigerating medium weight	620 g
Suitable for room area up to	- m²
Cooling capacity in watts (max)	4300 W
Cooling capacity in watts (min)	1400 W
Heating capacity in watts (max)	4400 W
Heating capacity in watts (min)	1100 W
Cooling capacity in watts (nominal)	3500 W
Cooling energy efficiency (EER, W/W)	3.9
Heating energy efficiency (COP, W/W)	3.93
Operating temperature (cooling) (T-T)	-15 - 50 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	8.5
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	3810 W
Seasonal efficiency rating (heating) (SCOP) (Warmer heating season)	5.8
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4.3
Current	10 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Design load (cooling)	3.3 kW
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling)	A+++
Power consumption (cooling) (max)	1650 W
Power consumption (cooling) (min)	120 W
Power consumption (heating) (max)	1480 W
Power consumption (heating) (min)	110 W
Annual energy consumption (cooling)	136 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Colder heating season)	- kW
Design load (heating) (Average heating season)	2.6 kW
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Warmer heating season)	628 kWh
Annual energy consumption (heating) (Average heating season)	847 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	200 mm
Indoor unit width	802 mm
Indoor unit height	295 mm
Indoor unit weight	8700 g
Cooling airflow (indoor unit)	520 m³/h
Indoor unit sound power level	60 dB
Indoor unit noise level (low speed)	21 dB
Indoor unit noise level (high speed)	37 dB
Outdoor unit depth	303 mm
Outdoor unit width	765 mm
Outdoor unit height	555 mm
Outdoor unit weight	26400 g
Outdoor unit noise level	55 dB
Cooling airflow (outdoor unit)	2200 m³/h
Outdoor unit sound power level	64 dB
