ComAp InteliCompact NT Reference Guide

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
157
Operating temperature
-30..+70 °C
14.11.3 IG-AVRi Trans/100
Primary voltage
100–120 V AC
Absolute low limit
100 V AC - 20%
Absolute high limit
120 V AC + 20%
Frequency
50–60 Hz
Secondary voltage
18 V AC
Operating temperature
-30..+70 °C
14.12 Governor output
Output type
0–10 V analog or 5 V @ 500 Hz PWM, selectable by jumper.
Serial resistor 10 kΩ shortable by jumper
Galvanic insulation
Not insulated
14.13 Remote communication interface
RS232
Optional using the plug-in module IL-NT RS232, D-SUB9M socket
RS485
Optional using the plug-in module IL-NT RS232-485, plug-in
terminal block
Baud rate
Depending on selected mode (up to 57600 bps)
USB
Optional using the plug-in module IL-NT S-USB
Ethernet
Optional using the plug-in module IB-Lite
14.14 Extension modules interface
Type
CAN bus
Galvanic insulation
Insulated, 500 V
Baud rate
250 kbps
Bus length
max. 200 m
Termination resistor
120 Ω, built-in, jumper activated
14.15 Interface to other controllers
Type
CAN bus, available in MINT type only
Galvanic insulation
Insulated, 500 V
Baud rate
250 kbps
Bus length
max. 200 m
