InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
Binary input: RevSyncDisable
If the input is active, the controller will not perform reverse synchronizing
when the mains have returned, but performs a changeover instead.
This input is to be used as an external MCB button for control of the breaker
in manual mode. It works the same way as the MCB button on the panel.
Binary input: Ext MF Relay
This input can be used for connecting an external mains protection relay. If
the input is activated, the controller will consider the mains to have failed
and will perform all appropriate actions.
Binary input: MainsFailBlock
If the input is active, the gen-set will not start after the mains fail although the
controller is in AUT mode. If the gen-set is already running and the input has
been activated, the timer ReturtnDel starts to count then the GCB is opened,
gen-set goes to cooling procedure and stops The input simulates healthy
mains.
NOTE:
THE MCB WILL CLOSE WHILE THE GCB IS OPENING!
16.4 Table of binary output functions
16.4.1 Common functions
Binary output: Starter
This output is dedicated for starter motor control.
NOTE:
Learn more about starting procedure in the chapter Engine start.
