ComAp InteliCompact NT Reference Guide

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
138
10 Binary output functions
10.1 Common functions
NOTE:
Learn more about wiring of binary outputs in the chapter Wiring of binary outputs.
1. Starter
2. Battery B
3. Fuel Solenoid
4. Stop Solenoid
5. Stop Pulse
6. Ignition
7. Prestart
8. Alarm
9. Horn
10. Fault Reset
11. GCB Close/Open
12. GCB ON Coil
13. GCB OFF Coil
14. GCB UV Coil
15. Speed Up
16. Speed Down
17. AVR Up
18. AVR Down
19. Ready To Load
20. Synchronizing
21. Running
22. Loaded
23. Unloading
24. AnalogSwitch 1
25. AnalogSwitch 2
26. AnalogSwitch 3
27. Ctrl HeartBeat
28. Gen Healthy
29. Yellow Alarm
30. Red Alarm
31. Mode OFF
32. Mode MAN
33. Mode AUT
34. Exerc Timer 1
35. Exerc Timer 2
36. Power Switch
37. Neutral CB C/O
38. Breaker Trip
39. kWh pulse
10.2 ECU info
1. ECU Comm OK
2. ECU Comm Error
3. ECU YellowLamp
4. ECU RedLamp
5. ECU PowerRelay
