MAIN HISTORY LOG SCREEN
NOTE:
The first history record after the controller is switched on, programmed or watchdog reset occurs
contains diagnostic values instead of operational values. Some fields in these records may have
nonsense values. Do not take these values into account.
5.7 Browsing alarms
The Alarmlist and ECU Alarmlist are displayed on the last two screens in the measurement page. If
the main screen is displayed, then the Alarmlist screen will appear automatically whenever a new
alarm occurs. It can be also displayed manually as described in the chapter View measured values.
 Use the button to move over the alarms in the ECU Alarmlist. Details of the selected
alarm are displayed in the bottom line.
 Press the button to reset alarms.
 Active alarms are displayed as white text on a black background. This means the alarm is
still active, i.e. the appropriate alarm conditions are still present.
 Inactive alarms are displayed as black text on a white background. This means the alarm is
no longer active, i.e. the appropriate alarm conditions are gone.
 Unconfirmed alarms are displayed with an asterisk. This means the alarm is still not
acknowledged (confirmed).
Inactive unconfirmed alarm
Active uncorfirmed alarm
Active confirmed alarm
Number of
alarms
ALARMLIST
Ecu AlarmList
>EngOil Press
000225 (00E1h)
*000600 (00258h)
________________________
FC 100 OC 1 FMI 1
Inactive unconfirmed alarm,
DTC numeric form
Active confirmed alarm,
DTC numeric form
Active but confirmed alarm
EngOil Press
000225 (00E1h)
Selected alarm indicator
Selected alarm details
ECU ALARMLIST
