InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
16.2 Table of values
16.2.1 Group: Engine
Value: RPM
This value contains the current engine speed. The value is obtained from
one of the following sources:
ECU, if an ECU is configured
Pickup input
Generator frequency
Learn more in the Speed measurement chapter.
Frequency measured on the pickup input if the setpoint Gear Teeth is
adjusted to zero and it is expected that the “W” terminal from the charging
alternator is connected to the pickup input.
Shows binary status (0 or 1) of ECU:
ECU Yellow Lamp
ECU Red Lamp
WaitToStrt
L/h or G/h – selectable in configuration (LiteEdit)
Current fuel consumption obtained from the ECU. Contains invalid flag if
ECU is not configured or if the particular ECU does not provide this value.
