Setpoint: Dwell Time
Group
Sync/Load Ctrl
Range [units]
0 … 25.0 [s]
Related
applications
All
Description
The period of time that the phase angle difference must be within +/- Phase
Window and voltage difference within Voltage Window before the breaker is
closed.
Setpoint: Freq Gain
Group
Sync/Load Ctrl
Range [units]
0 ... 200.0 [%]
Related
applications
All
Description
Gain of the frequency control PI loop.
Setpoint: Freq Int
Group
Sync/Load Ctrl
Range [units]
0 ... 100 [%]
Related
applications
All
Description
Relative integration factor of the frequency control loop.
Setpoint: Angle Gain
Group
Sync/Load Ctrl
Range [units]
0 ... 200.0 [%]
Related
applications
All
Description
Gain of the phase angle control loop.
During synchronization, first the frequency loop is started to match the
generator frequency with the mains or bus and after that the phase angle
loop is started to match the phase angle.
