This is the value of the analog input 3 of the controller. It will contain an
invalid flag if the input is not used or sensor fail is detected on it.
This is a bit array containing the status of the physical binary inputs of the
controller. Bit0 represents BI1, bit1 represents BI2, etc.
NOTE:
In LiteEdit and on the controller screen this value is displayed in “normal
order”, i.e. BI1 in the leftmost position
This is a bit array containing the status of the physical binary outputs of the
controller. Bit0 represents BO1, bit1 represents BO2, etc.
NOTE:
In LiteEdit and on the controller screen this value is displayed in “normal
order”, i.e. BO1 in the leftmost position.
This is the actual voltage on the speed governor output of the controller. In
the event that the output is switched to PWM mode, the relation is
10V ~ 100% PWM.
