Binary output: ExtBI 6 Status
This output gives information about the status of binary input 6 of the
extension module.
ï‚· If the related binary input is configured as an alarm input, the output
is closed when the assigned alarm is present in the alarmlist.
ï‚· If the related binary input is configured as functional, the output
copies directly the status of the input.
Binary output: ExtBI 7 Status
This output gives information about the status of binary input 7 of the
extension module.
ï‚· If the related binary input is configured as an alarm input, the output
is closed when the assigned alarm is present in the alarmlist.
ï‚· If the related binary input is configured as functional, the output
copies directly the status of the input.
Binary output: ExtBI 8 Status
This output gives information about the status of binary input 8 of the
extension module.
ï‚· If the related binary input is configured as an alarm input, the output
is closed when the assigned alarm is present in the alarmlist.
ï‚· If the related binary input is configured as functional, the output
copies directly the status of the input.
Binary output: AL AI1 Yel
The output is closed when there is the yellow alarm from the analog input 1
of the controller present in the alarmlist.
Binary output: AL AI2 Yel
The output is closed when there is the yellow alarm from the analog input 2
of the controller present in the alarmlist.
